Programmable motion sensor light switch manual#

2P units with -2SA, -2VA, or NL options: Both poles Manual On.WSX (PDT) 2P series: Pole 1 Auto on and Pole 2 Manual on.Units with -SA, -VA, or -NL option: Manual on.It has setting modes of "Automatic on", "Manual on" and "Reduced turn on". If the lights are ON, the sensor returns to maximum sensitivity. Weaker signals like reflections from glass will be ignored. Reduced turn-on directs the sensor to only turn on when there is a large motion like a person entering a room is detected. For manual on, you have to press the button to turn the lights on.

When occupancy is detected, automatic o turns lights ON. It has time settings including 30 sec, 2.5 min, 5.0 min, 7.5 min, 10 min, 12.5 min, 15 min, 17.5 min, 20 min, and 30 min. The time sensor keeps lights ON after occupancy detection. Sensor Operational Settings Occupancy time delay This technology adapts the sensor dynamically to its environment by filtering out constant background noise and detecting only noises typical of human activity. WSX sensors with PDT, first see motion using PIR and then engage Microphonics to listen for sounds that also determine continued occupancy. When the time delay is expired, lights are turned off automatically. These sensors have user-adjustable modes.Īfter the lights are turned on, an internal timer keeps them ON during brief periods of inactivity. In a dual relay sensor, when occupancy is detected, it will close pole 1's relay automatically while still required pole 2's push-button to be pressed for closing pole 2's relay. In a vacancy sensor, first pressed the push button of the vacancy sensor to initiate the lights ON. For an Auto-On sensor, an internal relay switch will ON on the connected lighting load once the occupancy is detected. WSX family sensors detect the changes in the passive infrared energy given off by occupants as they move within the field of view. Low prices on all Sensor Switch Spare Parts Order Now WSX Sensor Operation Then, consider that the programming has been done completely.

Once the new setting has been saved successfully, you can see the LED flashes confirmation twice.

Now, reselect the function to save and exit.

And, you need to release the button when LED flashes rapidly.

While LED flashes back on the new setting, press and holds the button.

While flashing, you have to select the new setting as per your requirements

When you selected the function, the flashes will begin.

Among all, you should press the suitable function that you want to change.

You can see there a number of functions such as occupancy time delay, on mode, switch mode, photocell set-point, LED operation, restore factory defaults, minimum on time, manual on the grace period, dual technology, microphone grace period, predictive exit time and predictive grace time. When it flashes, you need to release the button. You have to press and hold the push button on your device until it flashes.Here, you can see the Sensor Switch programming instructions briefly. You can change SensorSwitch operational settings with the help of a push-button sequence. Sensor Switch WSX Programming Instructions Sensor Switch WSX Programming Instructions.Ĥ.1 Does a Motion Sensor Switch Need a Neutral?Ĥ.3 How Do You Wire a Occupancy Sensor Switch?Ħ.
